1. introduction
The universal testing machine (UTM), also known as a universal
tester, materials testing machine, materials test frame or
tensometer, is used to test the tensile strength and compressive
strength of materials. It can perform many standard tensile and
compression tests on materials, components and structures, in other
words, that it is versatile.
2. specification
| Model | WTD-5/10/20/50 | WTD-100 | WTD-200/300 | WTD-500/600 |
| Max. capacity(kN) | 5/10/20/50 | 100 | 200/300 | 500/600 |
| Measuring range | 1%~100%FS(0.4%-100%FS) |
| Grade | Grade 1(Grade 0.5) |
| Force resolution | 1/400000 |
| Deformation measuring range | 2%~100%FS |
| Relative error of deformation value | +/-1%(+/-0.5%) |
| Deformation resolution | 1/400000 |
| Force speed | 0.01-50 kN/s |
| Deformation speed | 0.01-30mm/min |
| Displacement speed | 0.01-500mm/min (can be 1000mm/min) | 0.01-300mm/min | 0.01-250mm/min |
| Tensile fixture for round and flat specimen | Standard one set tensile fixture for round specimen, one set
tensile fixture for round specimen, one set of compression platen,
other test fixture can be equipped according to client’s
requirement or relative test method |
| Extensometer | According to test materials or client’s requirement |
| High and low temperature test | According to relative test method or client’s requirement |
| Max. stroke of crossbeam | 1090mm | 1070mm | 1140mm | 1200mm |
| Effective tensile space (equip with metal tensile fixture) | 800mm | 700mm | 600mm | 600mm |
| Distance between columns | 430mm | 550mm | 600mm | 625mm |
| Power | 220V,1.0kw | 220V,2kw | 220V,3kw | 380V,4kw |
| Dim. Of loading frame(cm) | 79x43x186 | 92x50x198 | 110x60x241 | 130x87x250 |
| Weight | 400kg | 700kg | 1150/1250kg | 2500kg |
1. How to choose the most suitable products?
Our professional team will give you the best suggestion as long as
you tell us what kind of test you
need to do and the required specification.
2. Do you accept customization service?
Yes, of course, Our factory can not only offer standard machines, but also customized machines
according to your request. Don’t hesitate to tell us your requirement, we will
try our best to meet your needs.
3. How about your warranty?
Generally, our warranty is 1 year. If you face any problems in future during testing process we
promise we will give you a reply within 24 hours and solution provide within 2 working
days. We can offer operation video and English operation manual. We can provide video.
4. What is the order process?
Inquiry - quotation - communication - order confirming - deposit
payment - production - testing and
debugging - balance payment - packing - delivery - customer
receiving - after service.
